The TSK TM and TMA(Full cover Type)-SERIES binders were developed to meet market demands for high quality product, quick-ready, operator-friendly interface, and reduced downtime and servicing.
Caste iron frames assure a lifetime of strength.
Optional digital gauges, with zeroing capability, assure precise no-fault settings within a tolerance of .01mm.
They are available with 14,16,18,21,24 clamps, in-lines configuration specifically to fit your factory floor space.
High quality and dependable controls assure consistent productivity with minimum downtime.
TSK's computer automation systems have proven themselves to be outstanding in the field.
Quick-ready and on-the-fly adjustments can be centrally, at each station, or all simultaneously from a job title date bank.
Customized for your specific requirements, available in English and / or other languages, the full system commands 23 adjustments for the fastest quick and control systems established on the market.
The state-of-the-art automatic 24-clamp make-ready type

Automatic work-size-input collectively make-ready function.
The vertical and horizontal sizes of cover and the thickness of signatures will be recorded by a measuring unit, and then data is collectively transferred to the equipment for make-ready(simple setting).
Make-ready data can be also stored as a memory.
Model
Stations
Format
Size
Max
mechanical
Speed
Power
Requirement
Dimensions
(mm)
Weight
CPH
L
W
H
kg
TMA-18
18
A6-B4
7,000
20kw
6,200
2,000
1,580
5,500
TMA-24
24
A6-B4
10,000
28kw
8,900
2,480
1,580
10,000
TMB-24 24 A6-B4 12,000 30kw 9,600 2,090 1,700 11,000

*TMA-18,TMA-24 is available with 14,16,18,21,24 clamps, too.
*Other number of station available.
